Pro L5160e Color Wide Format Printer
AnteriorSiguiente
Pro L5160e Color Wide Format Printer

Pro L5160e Impresora a color de formato ancho

Impresora a color de formato ancho

ID: 342362
Impulse el éxito en gran formato con una impresión de látex vibrante y confiable
  • Velocidades de impresión de hasta 46,7 m2/hr
  • Calidad de imagen de hasta 1200 x 1200 dpi
  • Imprima en material de rollo de hasta 1,63 m de ancho
  • Excepcional versatilidad de medios, mantenimiento automatizado y tinta blanca de látex
Call for a Quote: 866-230-2723
8am-5pm CT M-F
Already a Ricoh Customer? If you're already a customer of RICOH you can get your supplies by logging into MyRicoh to order.

Características

Download Brochure
  • Logre más éxito en formato ancho con vívido látex de Ricoh

    Logre más éxito en formato ancho con vívido látex de Ricoh

    La Pro L5160 de RICOH proporciona la ventaja que necesita para tener éxito. Con tintas de látex de resina acuosa (AR) de Ricoh y cabezales de impresión Ricoh de calidad industrial, ofrece una calidad de imagen excepcional, un color insuperable y productividad de hasta 502,5 pies2/hora. Ofrezca a los clientes una amplia gama de aplicaciones duraderas para interiores y exteriores, y agregue una impresión en blanco opaco para ampliar aún más sus capacidades.

  • Imprima más de las aplicaciones que buscan los clientes

    Imprima más de las aplicaciones que buscan los clientes

    Desde la señalización tradicional hasta las aplicaciones de alto valor, la Pro L5160 le brinda a su empresa la flexibilidad para crear resultados vibrantes y duraderos. Imprima pancartas, carteles, pantallas POP, envolturas de vehículos, revestimientos de paredes y decoración de interiores. La tinta blanca expande aún más las capacidades de su aplicación, lo que le permite imprimir en películas nítidas, medios en color y producir pantallas retroiluminadas de día / noche de múltiples capas.

  • La calidad de Ricoh comienza con tintas y cabezales de impresión avanzados

    La calidad de Ricoh comienza con tintas y cabezales de impresión avanzados

    Diseñados para ofrecer la calidad del primer día durante años de uso confiable, los cabezales de impresión MH5441 de Ricoh están construidos con acero inoxidable duradero y cuentan con 1.280 boquillas por cabezal de impresión con una resolución nativa de 600 ppp. Las capacidades de caída múltiple permiten 4 niveles de escala de grises, lo que garantiza una impresión precisa para obtener detalles nítidos, texto preciso y nítido, gradaciones suaves y tonos de piel realistas.

  • Operación de usuario simple y potente software RIP

    Operación de usuario simple y potente software RIP

    La Pro L5160 viene equipada con un intuitivo panel táctil de color de 4,3" y una zona de impresión brillante y accesible con grandes ventanas e iluminación. El potente software Onyx® RIPCenter™ viene de serie, lo que facilita el trabajo de configuración y optimización del trabajo para los operadores. Administre fácilmente el color con un motor de color propio y el último motor PDF de Adobe® para garantizar que su salida cumpla con las expectativas.

  • Diseñada para los entornos de producción más exigentes.

    Diseñada para los entornos de producción más exigentes.

    La frecuencia de corto plazo y cambio rápido está aumentando en el mercado, y la Pro L5160 lo ayuda a cumplir esos plazos con facilidad. Las tintas de látex de curado rápido, combinadas con calentadores inteligentes de 3 vías, hacen que la salida salga de la impresora curada y esté lista para el acabado o la instalación, reduciendo el tiempo necesario para completar el trabajo.

  • Las tintas de látex de Ricoh son seguras en casa, en el interior

    Las tintas de látex de Ricoh son seguras en casa, en el interior

    A diferencia de los sistemas de tinta a base de solventes, la salida creada con la Pro L5160 no es peligrosa ni tiene olores, por lo que es segura para ambientes interiores, incluidos el cuidado de la salud, la hospitalidad y la educación. Sirva al creciente mercado para la decoración de interiores, que incluye murales de pared, lienzos elásticos, papel de pared personalizado y cubiertas para ventanas para ayudar a los clientes a diseñar sus entornos de trabajo / vida.

  • Produzca señalización tradicional e impulse nuevas fuentes de ingresos

    Produzca señalización tradicional e impulse nuevas fuentes de ingresos

    Las tintas de látex AR de Ricoh mantienen su color contra los elementos, lo que las hace ideales para aplicaciones de señalización tradicionales, como pancartas para eventos al aire libre, banderas, envoltorios de vehículos, textiles, publicidad de tránsito, pantallas retroiluminadas día / noche, señalización publicitaria y gráficos de bienes raíces. Duraderas y resistentes a los rasguños, estas tintas ayudan a los clientes a presentar su mejor imagen, incluso en áreas con mucho tráfico.

  • Cree envases y etiquetas para satisfacer la creciente demanda.

    Cree envases y etiquetas para satisfacer la creciente demanda.

    La demanda de envases personalizados está explotando. Ayude a las marcas a diferenciarse mediante la creación de empaques, impresión y hojas adhesivas para empaques corrugados, y cree etiquetas para alimentos y bebidas, cosméticos u otros productos en pequeñas cantidades sin invertir en impresoras de etiquetas exclusivas. Imprima pruebas de embalaje de forma rápida y rentable para ayudar a los clientes a evaluar sus opciones antes de la producción.

  • ¿Necesitas más información?

    Conoce más acerca de la impresora a color de formato ancho Pro L5160 de RICOH y cómo puede ser ideal para tu empresa.

Especificaciones

  • Nombre del modelo de suministros
  • Sistema operativo compatible
  • Fuente de papel
  • Ancho de papel original
  • Peso de papel original
  • Alimentación original
  • Capacidad de memoria
  • Espesor máximo
  • Consumo máximo de energía
  • Tipo de tinta
  • Disco duro
  • Descargar la hoja de especificaciones
  • Idiomas compatibles
  • Dimensiones AxPxH
  • Proceso de impresión de copias
  • Software compatible
  • Tecnología
  • Lema de introducción
  • Formatos de archivo compatibles
  • Velocidad de impresión
  • Resolución de impresión
  • CPU
  • Peso
  • Resolución
  • Fuente de alimentación
Nombre del modelo de suministros
Pro L5160e
Nombre del modelo de suministros
Pro L5160e
Sistema operativo compatible
Sistema operativo para PC instalado: Windows 7 64 bit (Professional, Enterprise, Ultimate), Windows 8.1 64bit (Professional, Enterprise) o Windows 10 64bit (Professional, Enterprise)
Fuente de papel
Rodar
Ancho de papel original
63.6” (1,615mm)
Peso de papel original
Peso de los medios: máximo 121 lbs. (55 kg) o menos
Alimentación original
Tipo de soporte: vinilos autoadhesivos, películas, papeles, lienzos, pancartas, materiales sintéticos, mallas, telas / textiles
Capacidad de memoria
Memoria RIP del software Ricoh: 16 GB o más
Espesor máximo
Hasta 0,43 mm (17 mil)
Consumo máximo de energía
Operar: 600W | Stand by: 5.35W | Apagado: 0.5W
Tipo de tinta
Tinta de látex (2ª generación de tinta AR)
Disco duro
750GB o más
Descargar la hoja de especificaciones
/PDFs/Brochures/prol5160_ES_LA.pdf
Idiomas compatibles
RICOH Software RIP: japonés, inglés, italiano, griego, español, checo, alemán, francés, polaco, portugués, chino (simplificado / tradicional), coreano
Dimensiones AxPxH
128.3” × 39.3” × 58”| (3,259 × 999 × 1,472mm)
Proceso de impresión de copias
Sistema de inyección de tinta piezoeléctrico a pedido (3 cabezales de impresión de grado industrial RICOH MH5441 - configuración escalonada)
Software compatible
Onyx, ColorGate, SAi, Caldera y Wasatch
Tecnología
Chorro de tinta
Lema de introducción
Impulse el éxito en gran formato con una impresión de látex vibrante y confiable
Formatos de archivo compatibles
Software RICOH Formatos de entrada RIP: EPS, PS, PDF, prueba remota, Targa, TIFF, JPEG, BMP, DIB, Scitex CT, JPEG, PSD, PSD grande, GIF, brocha PC, Photo CD, MrSID, ILS, PNG, JDF
Velocidad de impresión
Modo de producción: hasta 502.5 pies cuadrados por hora.
Resolución de impresión
Impresión a todo color (CMYK) | 6 pases 600 ppp x 450 ppp | 8 pases 600 ppp x 600 ppp | 12 pases 600 ppp x 900 ppp | 16 pases 600 ppp x 1200 ppp | 32 pases 1200 ppp x 1200 ppp
CPU
RICOH Software RIP CPU: Intel Core i7 o posterior
Peso
820.1 lbs. (372 kg)
Resolución
450dpi, 600dpi, 900dpi, 1200dpi
Fuente de alimentación
AC208-240V 16A 50 / 60Hz × 2 líneas
