D5510 Quadro interativo

Quadro Branco Interativo

ID: 431193
Melhore suas ideias em tempo real
  • Apresente em um painel de visualização, de 55"
  • Revise, edite e compartilhe apresentações
  • Autenticação de código PIN de usuário remoto
  • Resolução máxima de 1920 x 1080 dpi
Call for a Quote: 866-230-2723
8am-5pm CT M-F
Already a Ricoh Customer? If you're already a customer of RICOH you can get your supplies by logging into MyRicoh to order.

Características

Download Brochure
  • Colabore em qualquer lugar

    Colabore em qualquer lugar

    Poupe tempo e despesas criando reuniões colaborativas em tempo real com o Lousa Interativa D5510 da RICOH. Opções de visualização padrão permitem que até 20 usuários assistam a uma apresentação em quadro branco em dispositivos conectados à Internet. Com a licença de software opcional, é possível conectar até 20 quadros brancos ao mesmo tempo, em diversos locais. É um modo rápido, fácil e econômico de reunir virtualmente participantes distantes.

  • Pronto. Definir. Compartilhar.

    Pronto. Definir. Compartilhar.

    A instalação é rápida e fácil. Basta conectar o D5510 a seu PC, tablet etc., e seguir as instruções para iniciar. A navegação inclui ícones que espelham as aplicações empresariais de uso diário, portanto é fácil fazer o ajuste fino dos controles do sistema e gerenciar apresentações sem grande esforço nem procura.

  • Mude a direção

    Mude a direção

    Maximize o tempo de sua reunião e colabore com a equipe interativamente, no local ou externamente. Modifique usando ferramentas de quadros brancos para redigir, desenhar, editar, mudar o tamanho, mover e salvar informações de modo fácil. Além disso, os quadros brancos conectados são espaços comuns - o que for adicionado a um quadro aparecerá em todos os outros em rede.

  • Colabore com plateias grandes e pequenas

    Colabore com plateias grandes e pequenas

    Tudo o que tem a fazer é escolher os participantes e decidir como as informações serão mostradas. Conecte o quadro branco a um projetor e exiba as apresentações para plateias maiores. Vincule-o a outros quadros brancos remotos. Use-o como uma tela de alta qualidade empregando um sistema opcional de videoconferência, ou apenas convide espectadores remotos para participar e assistir à reunião usando PC, tablet, smartphone etc., - como else se conectarão fica a seu critério.

  • Proteja e preserve sua apresentação

    Proteja e preserve sua apresentação

    Mantenha as apresentações reservadas por meio de login com autorização por código PIN. Além disso, salve a apresentação como arquivo PDF pesquisável - incluindo notas manuscritas - em uma unidade USB, diretório compartilhado de rede ou mesmo temporariamente na unidade de estado sólido do quadro. Para proteger sua apresentação, os dados são apagados no momento em que você desliga o equipamento. Ou, simplesmente proteja o documento com nome e senha no quadro branco e depois, envie-o por e-mail diretamente do quadro aos participantes.

  • Precisa de mais informações?

    Saiba mais sobre como a Lousa Interativa D5510 da RICOH poderá ajudar a exibir sua próxima apresentação.

Especificações

  • Número máximo de espectadores remotos
  • Nome do modelo de suprimentos
  • Sistema operacional
  • slogan de introdução
  • Peso
  • Saida de video
  • Entrada de vídeo
  • Funções do usuário
  • Função de compartilhamento remoto
  • Operação remota para PC
  • Fonte de energia
  • Outras características
  • Outro
  • Interfaces
  • Recursos aprimorados
  • Dimensões L x A x P
  • Saída de áudio
  • Tempo de inicialização
  • Modo de espera
  • Tempo de recuperação do modo de espera
  • Consumo de energia
  • Temperatura de operação
  • Umidade operacional
  • Ruído
  • Limitação de altitude
  • Compartilhamento
  • Colaboração
  • Visualização angulo HV
  • Resposta Speen
  • Resolução
  • Pitch de pixel
  • Tamanho do painel
  • Área de exibição efetiva L x A
  • Tipo de exibição
  • Cor exibida
  • Taxa de contraste
  • Brilho
  • Luz de fundo
  • Proporção da tela
  • SSD
  • RAM
  • Sistemas operacionais
  • CPU
Número máximo de espectadores remotos
até 20 por quadro branco
Número máximo de espectadores remotos
até 20 por quadro branco
Nome do modelo de suprimentos
D5510
Nome do modelo de suprimentos
D5510
Sistema operacional
Windows Embedded Standard 7
slogan de introdução
Melhore suas ideias em tempo real
Peso
Menos de 45 kg
Saida de video
DVI x 1
Entrada de vídeo
Unidade da Tela: Mini D-SUB 15 pinos x 2, DisplayPort, HDMI (HDCP x 1), HDMI (PC) x 1
Funções do usuário
Caneta de 20 cores, Selecionar, Deletar (Apagar), Desfazer/Refazer, Salvar para USB/Pasta da Rede/ Quadro Branco Interativo, Abrir Arquivos PDF e PPT de USB e Pasta da Rede, Selecionar Página da Tela, Capturar Página, Adicionar Nova Página, Lista de Páginas Capturadas, Apagar Página, Copiar Página, Função Marcador, Baixar Firmware Automaticamente
Função de compartilhamento remoto
Até 8 Quadro Branco Interativos e Equipamentos de projeção Até 20 visualizadores de navegadores por Quadro Branco Interativo
Operação remota para PC
Sim
Fonte de energia
100 - 240 V, 50/60 Hz
Outras características
Caneta eletrônica do sistema de deteção: Método de interceptação da luz, Espessura do Vidro de Proteção: Aprox. 2mm (incluindo revestimento AR)
Outro
O brilho depende do modo de entrada e de outras configurações da imagem.
Interfaces
Porta USB : USB2.0 TIPO-A x 2,
Recursos aprimorados
Imagem-em-Imagem (Picture-in-Picture), Zoom, Função de Recuperação, Email, Impressão de Página, Forma de Salvar Dados: PDF v1.4, Máx. de criação de páginas: 100, e Máx. de traços/página: 3.000
Dimensões L x A x P
1.360 x 125 x 830 mm
Saída de áudio
Pinos (R+L) e terminais para alto-falantes 10W + 10W
Tempo de inicialização
Menos de 50 seg.
Modo de espera
Menos de 45W
Tempo de recuperação do modo de espera
Cerca de 5 segs.
Consumo de energia
Menos de 200W
Temperatura de operação
10°C - 32°C
Umidade operacional
15% - 80%
Ruído
Menos de 40dB
Limitação de altitude
Mais baixa que 2.000 m (ao nível do mar)
Compartilhamento
Yes
Colaboração
Yes
Visualização angulo HV
160°/160° (Taxa de Contraste >= 10)
Resposta Speen
6,5 ms (Cinza para Cinza, Média )
Resolução
Máximo: 1.920 x 1.080 dpi
Pitch de pixel
0,63 x 0,63mm
Tamanho do painel
Diagonal: 55" (138,7 cm) de largura
Área de exibição efetiva L x A
1.209 x 680,4mm
Tipo de exibição
Tela de Cristal Líquido
Cor exibida
Máximo: Mais de 16.770.000 cores
Taxa de contraste
2.670 : 1
Brilho
Máximo: 300 cd/m²
Luz de fundo
Sistema LED
Proporção da tela
16 : 9
SSD
80 GB
RAM
8 GB
Sistemas operacionais
Windows Embedded Standard 7 (64-bit)
CPU
Intel iCore3 4330 3.5GHz
